Revopac Packaging Technology Co., Ltd（briefly as REVOPAC）located in Jinshan District of Shanghai, is engaged in the design, development, manufacture and sales of robotic packaging & palletizing systems. In 2015, the company was acquired by a public company—Shanghai Ailu Package Co., Ltd (stock code:830970).
REVOPAC processes the cutting-edge packaging technologies in various industries such as chemical, food, building material, metallurgy and mineral. Rather than a bagging machine manufacturer, we’re a full-line provider which can deliver complete bagging line solutions including product conveying, filling, weighing, packaging, palletizing and further stretch-hooding. Moreover, REVOPAC provides tailor-made system and prompt after-sales service for our customers.
Most of REVOPAC team members were from world-class packaging companies and are with overseas working experiences. At REVOPAC, we believe customer experience and benefit are second to none in solution design and actualizing such. We aim to be a value creator, rather than a solution provider.



REVOPAC Packaging Technology Co., Ltd is a fully owned subsidiary by Ailu Group

INNOVATIVE SOLUTIONS DELIVER CUSTOMER VALUE

REVOPAC FILLING FAMILY

AIR FILLING SYSTEM

filling1

The air filling system introduces compressed air into the filling chamber to homogenize & fludize the product and then conveys the product into the bag.

IMPELLER FILLING SYSTEM

filling2

Impeller filling system is specially designed for filling loose,free-flowing/flow-resistant powdery product into the bag.Product filling is realized by an impeller which is driven by a motor with adjustable speed control.

PUMP FILLING SYSTEM

filling3

Product is introduced into the bag by means of a specially designed powder pump.Compared with traditional vacuum filling system, this design provides less energy consumption, higher filling capacity and accuracy.

EXPERIENCE IN PRODUCT HANDLING

丰富的物料处理经验

We design feeding system by analysis critical data such as bulk density , mesh ,fluidity ,moisture content repose angle etc.

丰富的物料处理经验

We only engage in the project which target material we fully comprehend and confident with ,or else we won’t contract us. This is the principle of our work.

丰富的物料处理经验

Based on the analysis of target material and our solid experience. REVOPAC developed various packer machine designed for different aterial.

VALVE BAG PACKAGING TECHNOLOGY

An air filling system is used to fill products with the following product characteristics: free flowing, mealy, powdery and grainy. The product is filled via a hopper into a fluidizing tank and is fluidized by supply air through a permeable mesh. When the dosing unit opens, air conveyors the product from the pressure chamber into the bag. The amount of conveying air can be adjusted to the specific type of product.

  • Clean filling by the product-orientated filling devices and parts

  • High weighing accuracy due to optimized dosing system

  • Easy operation and maintenance

  • Hygiene design available

阀口袋包装机

OPEN-MOUTH BAG PACKAGING TECHNOLOGY

敞口袋包装机

  • Designed for multipled dosing systems such as impeller, auger, air, etc.

  • Bag application system compatible with woven PP, plastic and paper bags

  • Dust tight filling spout design

  • High accuracy due to optimized dosing system

FIBC PACKAGING TECHNOLOGY

When compared to conventional bags, FIBC represents a cost effective alternative within the logistical supply chain for handling loose, bulk materials. REVOPAC FIBC filling technologies provide customized solutions satisfying customers’ requirements of all sorts.

  • High filling accuracy

  • Cleaning filling and therefore production environment improved

  • Automatic bag loading available via robotic bag applicator

吨袋包装机

ROBOTIC BAG PLACER

Mini robotic bag placer is mechanical device that could place the bag automatically to the filling spout

机器人上袋机

  • Minimum Space requirement

  • Loading capacity up to 450 bags/h per filling spout

  • Labor force remarkably saved

  • Efficiency improved

ROBOTIC BAGGING & PALLETIZING SYSTEM

The integrated robotic valve bag packaging machine providesa unique alternative in dealing with the bagging capacity lower than 120 bags/h. compared with conventional bagging and palletizing line, this system is featured with the following:

  • Multitasked

    Bag picking-up, loading, unloading, palletizing as well as pallet/sheet picking-up can be realized by one single robot. No additional operator will be needed during bagging & palletizing process.

  • Less space requirement

    From bag filling to palletizing—no additional conveyors will ever be required. Therefore the space required to install integrated robotic packaging system will be reduced to the minimum.

  • Cost-competitive

    Highly integrated system simplified the bagging process. Therefore parts commonly used on conventional bagging & palletizing line are saved. This in turn, will ultimately benefit our customers.

机器人包装&码垛系统

HIGH LEVEL PALLETIZER

REVOPAC’s high level palletizer realizes accurate palletizing of package in bags or bundle as well as carton. Thanks to its modular design, it’s highly compatable with the lay out on site.It is easy to install and economic in operation and maintenance. In addition, its construction and frame work is quite solid which guarantees the long hour operation with smooth mechanical moves but very little sound.

  • Adaptable to all conventional packing patterns to make the production flexible

  • Gentle bag handling to avoid unnecessary production loss

  • Low noise level to improve working conditions

  • The design, selection and execution of moving & controlling parts are aiming to deal with 7×24 operation. system stability and robustness can be maximally guaranteed

高位码垛设备

PALLETLESS STRETCH HOOD SYSTEM

The idea that uses the goods themselves as the load platform and eliminates the transport pallet now comes true by REVOPAC Palletless Technology. Compared with conventional pallet loading technology, Palletless packaging proves itself superior in terms of cost, goods protection, and load security etc.

  • Eliminates all pallet costs and energy and film consumption greatly reduced

  • Ruggedized transport loads

  • Watertight packaging, storable outdoors in all weathers

  • Environment-friendly recyclable package

  • Maximum efficiency

INTELLIGENT FILLING LINE SUPPLIER

REVOPCA is not the packer manufacturer but also the integrator of full packing lines.We are capable of provide one-stop solution to the full packing line which includes conveyor system, palletizing system, stretch hood equipment.

智能灌装整线提供商

WE OFFER PROMPT PR-SALES AND AFTER-SALES SERVICE

  •  Project analysis
  •  Project communication
  •  Product analysis
  •  Bagging trial
  •  Equipment optimization
  •  Installation and commissioning
  •  Training service
  •  Spare Part Service
  •  Inspection&Maintenance
  •  Pre-maintenance
